RU Series Universal Relay
Environmentally friendly relay that is lead wire free, cadmium-free.
[Features]
· Environmentally friendly relay that is lead wire free, cadmium-free.
· We offer solder terminal type and printed circuit board terminal type.
· Bidirectional high brightness operation display LED standard equipment (solder terminal type).
· Standard equipped with mechanical indicator for checking contact operation status (solder terminal type).
· Can perform circuit check without leaving an impression on the coil, and models equipped with latching lever for distinguishing AC coil and DC coil color also available.
· Standard equipped with marking plate (yellow).
· Replaceable, and can be used for relay identification.
· Maximum contact rating is: RU2 model: 10A, RU4 model: 6A, RU42 model: 3A.
· Product Safety of Electrical Appliance and Material act compliant.
· UL, CSA, c-UL certified, and conforms to EN regulations.
· Lloyd's Register of Shipping certified.
Part Number
Configured Part Number is shown.
| Part Number |
|---|
| RU2S-A100 |
| RU2S-C-A100 |
| RU2S-CR-A100 |
| RU2S-R-A100 |
| RU4S-A100 |
| RU4S-C-A100 |
| RU4S-CR-A100 |
| RU4S-R-A100 |
| RU42S-A100 |
| RU42S-C-A100 |
| RU42S-CR-A100 |
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | Application | Contact Configuration | Latch function | Contact rated current (minimum value for AC and DC) (A) | Coil rated voltage (DC) (V) | Coil rated voltage (AC) (V) | Contact Resistance | Release Time (ms) | Contact Material | Insulation Resistance (MΩ) | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
MYR 65.24 | 1 Piece(s) | 5 Day(s) or more | For Signals | 2c | Latching Relay | 10 | - | 100–110 | Standard Form | Single | Ag Alloy | 2-Pole | - | ||
MYR 53.46 | 10 Piece(s) | 6 Day(s) or more | For Signals | 2c | NA | 10 | - | 100–110 | Standard Form | Single | Ag Alloy | 2-Pole | 100 | ||
MYR 92.93 | 1 Piece(s) | 5 Day(s) or more | For Signals | 2c | NA | 10 | - | 100–110 | With CR Circuit | Single | Ag Alloy | 2-Pole | - | ||
MYR 92.93 | 1 Piece(s) | 5 Day(s) or more | For Signals | 2c | Latching Relay | 10 | - | 100–110 | With CR Circuit | Single | Ag Alloy | 2-Pole | - | ||
MYR 67.67 | 1 Piece(s) | 5 Day(s) or more | For Signals | 4c | Latching Relay | 6 | - | 100–110 | Standard Form | Single | Ag | 4-Pole | - | ||
MYR 67.67 | 1 Piece(s) | 5 Day(s) or more | For Signals | 4c | NA | 6 | - | 100–110 | Standard Form | Single | Ag | 4-Pole | - | ||
MYR 95.36 | 1 Piece(s) | 5 Day(s) or more | For Signals | 4c | NA | 6 | - | 100–110 | With CR Circuit | Single | Ag | 4-Pole | - | ||
MYR 95.36 | 1 Piece(s) | 5 Day(s) or more | For Signals | 4c | Latching Relay | 6 | - | 100–110 | With CR Circuit | Single | Ag | 4-Pole | - | ||
MYR 97.11 | 10 Piece(s) | 43 Day(s) or more | Power | 4c | Latching Relay | 3 | - | 100–110 | Standard Form | Twin | AgNi | 4-Pole | 10 | ||
MYR 71.81 | 10 Piece(s) | 6 Day(s) or more | For Signals | 4c | NA | 3 | - | 100–110 | Standard Form | Twin | AgNi | 4-Pole | 100 | ||
MYR 119.96 | 10 Piece(s) | 43 Day(s) or more | Power | 4c | NA | 3 | - | 100–110 | With CR Circuit | Twin | AgNi | 4-Pole | 10 |
Loading...
Basic Information
| Terminal shape | Solder | Representative Standard | CE / UL / CUL / TUV / CSA | Dimension height(mm) | 41.4 |
|---|---|---|---|---|---|
| Dimension width(mm) | 21 | Dimension depth(mm) | 27.5 | Operate Time(ms) | ○ |
Specification/Dimensions
-
Application
- For Signals
- Power
-
Contact Configuration
- 2c
- 4c
-
Latch function
- Latching Relay
- NA
-
Contact rated current (minimum value for AC and DC)(A)
-
Coil rated voltage (DC)(V)
-
Contact Resistance
- Standard Form
- With CR Circuit
- With Forward Polarity Diode
-
Release Time(ms)
- Single
- Twin
-
Contact Material
- Ag
- Ag Alloy
- AgNi
-
Insulation Resistance(MΩ)
- 2-Pole
- 4-Pole
-
Operating Temperature
- 10
- 100
-
Coil rated voltage (AC)(V)
Days to Ship
-
- All
- 5 Day(s) or Less
- 6 Day(s) or Less
- 43 Day(s) or Less
Specify Alterations
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
